The Haynes Manual On Fault Codes

By: Charles White .

The Haynes Manual On Fault Codes - Engine management & fuel injection codes. Cars and light commercial vehicles. A book by Charles White and Martynn Randall. Step-by-step illustrated procedures and fault code tables.

The definitive DIY manual on automotive diagnostic fault codes.
Covers code retrieval with and without a fault code reader.
Includes fault code tables (including EOBD systems), sensor and actuator tests, maker-specific chapters and code clearing procedures.
Unique colour section shows location of EOBD diagnostic plugs.

Systems covered:

• Bosch KE-Jetronic
• Bosch KE-Motronic
• Bosch LH-Jetronic
• Bosch Mono-Jetronic
• Bosch Mono-Motronic
• Bosch Motronic
• Daihatsu MPi
• Bosch EZ-K and EZ-L Ignition
• Fenix
• Ford EEC IV and EEC V
• GM/Delco SPi
• GM Multec
• Isuzu I-Tec
• Lucas 11 CU and 14CUX
• Lucas LH
• Magneti-Marelli G5 and G6
• Magneti-Marelli 8F and 8P
• Mazda EGi
• Mercedes HFM and PMS
• Mitsubishi ECI-Multi
• Nissan ECCS
• Proton ECI-Multi and ECI-SEFi
• Renix
• Rover MEMS
• Rover PGM-Fi
• Saab Trionic
• Siemens Bendix MPi
• Siemens MS4.0
• Simos
• Simtec
• Subaru MPFi
• Suzuki EPi
• Toyota TCCS
• VAG MPi and MPFi
• VW Digifant
• Weber-Marelli IAW
