Honda XL500S, XL500R, XR500, XR500R, XL600R, XR600R 1979 - 1990 Workshop manual (CM3398)

By: Clymer .

Models Covered

This detailed, comprehensive manual covers the Honda XL and XR 500-600 series singles from 1979-1990:

• XL500S (1979-1981)

• XL500R (1982)

• XR500 (1979-1980)

• XR500R (1981-1984)

• XL600R (1983-1987)

• XR600R (1985-1990)

Description

The expert text gives complete information on maintenance, tune-up, repair and overhaul. Hundreds of photos and drawings guide you through every step. The book includes all you will need to know to keep your Honda running right. Throughout this book where differences occur among the models, they are clearly identified.

A shop manual is a reference. You want to be able to find information fast. As in all Clymer books, this one is designed with you in mind. All chapters are thumb tabbed. Important items are extensively indexed at the rear of the book. All procedures, tables, photos, etc., in this manual are for the reader who may be working on the bike for the first time or using this manual for the first time. All the most frequently used specifications and capacities are summarized in the Quick Reference Data pages at the front of the book.

Keep the book handy in your tool box. It will help you better understand how your bike runs, lower repair costs and generally improve your satisfaction with the bike.

Every Clymer manual contains hundreds of original photographs and illustrations developed from a complete disassembly and assembly of the motorcycle. This, in addition to extensive research, allows Clymer to achieve an unmatched level of detail, accuracy and clarity.

Chapters

• Quick Reference Data
• General Information
• Troubleshooting
• Lubrication, Maintenance and Tune-up
• Engine
• Clutch and Transmission
• Fuel and Exhaust Systems
• Electrical System
• Front Suspension and Steering
• Rear Suspension
• Brakes
• Index
• Wiring Diagrams
