Honda XL/XR600R and XR650L/R 1983 - 2020 Service & Repair Manual (M2183)

Make

Honda

Model

XL600
XL600 Transalp
XR600R
XR650R/L

Year

1983 - 2020

This manual's year range represents the years of coverage available when the manual was written. The vehicle or machine's production years may extend beyond these dates.

Sub-Model

PD03, PD06, PD10
PE04
RE01

Engine

XL600R Transalp Petrol (PD03E)
XR600R Petrol (PE04)
XR650L Petrol (RD062)
XR650R Petrol (RE01A)

With a Haynes manual, you can do-it-yourself...from simple maintenance to basic repairs. Haynes writes every book based on a complete teardown of the bike, where we learn the best ways to do a job and that makes it quicker, easier and cheaper for you. Haynes books have clear instructions and hundreds of photographs that show each step. Whether you are a beginner or a pro, you can save big with a Haynes manual!



This manual features complete coverage for your Honda XL600R, XR600R, XR650L and XR650R motorcycle built from 1983 to 2020, covering:

• Routine maintenance
• Tune-up procedures
• Engine repair
• Cooling and heating
• Air conditioning
• Fuel and exhaust
• Emissions control
• Ignition
• Brakes
• Suspension and steering
• Electrical systems, and
• Wring diagrams
