Honda CB500F/X and CBR500R 2013 To 2020 Service & Repair Manual (M6301)

With a Haynes manual, you can do-it-yourself...from simple maintenance to basic repairs. Haynes writes every book based on a complete teardown of the motorcycle, where we learn the best ways to do a job and that makes it quicker, easier and cheaper for you. Haynes books have clear instructions and hundreds of photographs that show each step. Whether you are a beginner or a pro, you can save big with a Haynes manual!

This manual features complete coverage for your Honda CB500F/X & CBR500R built from 2013 through 2020, covering:

• Routine maintenance
• Tune-up procedures
• Engine repair
• Fuel and exhaust
• Emissions control
• Ignition
• Brakes
• Suspension and steering
• Electrical systems, and
• Wring diagrams

Make

Honda

Model

CB500F
CB500X
CBR 500R

Year

2013 - 2020

This manual's year range represents the years of coverage available when the manual was written. The vehicle or machine's production years may extend beyond these dates.

Sub-Model

PC44
PC45
PC46
PC57
PC58
PC59
PC62, PC62A
PC63, PC71
PC64, PC72

Engine

500 Petrol (PC44E)
500 Petrol (PC62E)
CB500F Petrol (PC44E)
CB500F Petrol (PC62E)
CB500X Petrol (PC44E)
CB500X Petrol (PC62E)
