Harley-Davidson Shovelheads 1966 - 1984 Workshop Manual (CM420)

Published by Clymer - M420, ISBN: 9780892875665, Paperback, this Harley-Davidson Shovelhead Manual is 432 pages.

Harley-Davidson FL, FXE, FLH, FXEF, FXB, FLHS, FXS, FXSB, FX, FXWG, SUPER GLIDE (FL) and ELECTRA GLIDE (FL) manual.

Includes Color Wiring Diagrams.

Clymer motorcycle repair manuals are written specifically for the do-it-yourself enthusiast. From basic maintenance to troubleshooting to complete overhaul, Clymer manuals provide the information you need. The most important tool in your tool box may be your Clymer manual, get one today.

Models Covered:

Harley-Davidson FL Shovelhead (1973-1984)
Harley-Davidson FXE Shovelhead (1974-1984)
Harley-Davidson FLH Shovelhead (1974-1984)
Harley-Davidson FXEF Shovelhead (1980-1984)
Harley-Davidson FXB Shovelhead (1980-1984)
Harley-Davidson FLHS Shovelhead (1980-1983)
Harley-Davidson FXS Shovelhead (1978-1984)
Harley-Davidson FXSB Shovelhead (1980-1984)
Harley-Davidson FX Shovelhead (1973-1979)
Harley-Davidson FXWG Shovelhead (1980-1984)
Harley-Davidson Super Glide FL Shovelhead (1971)
Harley-Davidson Electra Glide FL Shovelhead (1966-1972)

Contents:

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION

CHAPTER TWO / TROUBLESHOOTING
Emergency troubleshooting / Engine starting / Engine noises / Engine lubrication / Clutch / Electrical problems / Breaker point ignition troubleshooting / Breakerless ignition troubleshooting / Excessive vibration / Carburetor troubleshooting / Specifications

CHAPTER THREE / PERIODIC LUBRICATION, MAINTENANCE AND TUNE-UP Maintenance schedule intervals / Periodic lubrication / Periodic maintenance / Engine oil and filter change / Suspension adjustment / Breaker point ignition service / Breakerless ignition service / Carburetor adjustments / Specifications

CHAPTER FOUR / ENGINE
Removal installation / Rocker arm cover / Cylinder head / Pushrods / Valves and components / Cylinder / Pistons and rings / Oil pump / Gearcase cover and timing gears / Crankcase / Specifications

CHAPTER FIVE / CLUTCH, PRIMARY DRIVE, TRANSMISSION AND KICKSTARTER
Primary chain / Primary belt / Compensating sprocket / Primary chain/belt case / Transmission / Hand shifter cover (1966-early 1978) / Foot shifter (1966-early 1979) / Shifter cover (late 1979-1984) / Shift forks / Kickstarter and starter clutch / Side cover (electric start) / Electric starter drive / Shifter adjustment / Specifications

CHAPTER SIX / FUEL AND EXHAUST SYSTEMS
Air cleaner / Carburetors / Throttle cable / Fuel tank / Fuel supply valve / Exhaust system / Specifications

CHAPTER SEVEN / ELECTRICAL SYSTEM
Charging system / Voltage regulator (1966-1969) / Circuit breaker / Ignition system / Ignition coil / Starter / Starter solenoid / Lighting system / Switches / Horn / Fuses and circuit breakers / Specifications

CHAPTER EIGHT / FRONT SUSPENSION AND STEERING
Front wheel / Front hub / Wheel balance / Tire changing / Handlebar and throttle control / Steering head / Front fork / Specifications

CHAPTER NINE / REAR SUSPENSION
Rear wheel / Rear hub / Driven sprocket assembly / Drive chain / Drive belt / Wheel balancing / Tire changing / Rear swing arm / Shock absorbers / Specifications

CHAPTER TEN / BRAKES
Rear drum brake (1966-1972) / Disc brakes / Disc brake pad replacement / Brake caliper / Brake disc / Rear master cylinder / Brake hose replacement / Bleeding the system / Specifications

INDEX

COLOR WIRING DIAGRAMS
