Harley-Davidson FLH FLT FXR Evolution 1984 - 1998 Workshop Manual (CM4223)

Published by Clymer, ISBN: 9780892879168, Paperback, This Harley Davidson Motorcycle Manual is 944 pages.

Includes Color Wiring Diagrams.

Clymer motorcycle repair manuals are written specifically for the do-it-yourself enthusiast. From basic maintenance to troubleshooting to complete overhaul, Clymer manuals provide the information you need.

Models Covered:

• FLHR Road King (1995-1998)
• FLHR-I Road King (1996-1997)
• FLHRC-I Road King (1998)
• FLHS Electra Glide Sport (1988-1993)
• FLHT Electra Glide (1995-1998)
• FLHTC Electra Glide Classic & Anniversary (1984-1998)
• FLHTC-I Electra Glide Classic (1996-1998)
• FLHTC-U Electra Glide Classic-Ultra & Anniversary (1989-1997)
• FLHTC-UI Electra Glide Classic-Ultra & Anniversary (1996-1998)
• FLTC Tour Glide (1984-1991)
• FLTC-U Tour Glide-Ultra Classic (1989-1995)
• FLTC-UI Tour Glide-Ultra Classic (1996)
• FLTR Road Glide (1998)
• FLTR-I Road Glide (1998)
• FXEF Fat Bob (1985)
• FXLR Low Rider, Custom & Anniversary (1987-1994)
• FXR Super Glide (1986-1994)
• FXR2 & FXR3* Super Glide (*Limited edition models available only in 1999)
• FXRD Super Glide Grand Touring (1986)
• FXRS Low Rider & Convertible (1984-1992)
• FXRS-Con Low Rider-Convertible (1991-1993)
• FXRS-SP Low Rider-Sport Edition (1988-1993)
• FXRT Sport Glide (1984-1992)
• FXSB Low Rider (1985)
• FXWG Wide Glide (1985-1986)

Contents:

QUICK REFERENCE DATA

CHAPTER ONE / GENERAL INFORMATION
Manual organization / Warnings, cautions and notes / Safety / Serial numbers / Fasteners / Shop supplies / Basic tools / Special tools / Precision measuring tools / Electrical system fundamentals / Basic service methods / Storage / Specifications

CHAPTER TWO / TROUBLESHOOTING
Engine principles / Operating requirements / Starting the engine / Engine performance / Starting system / Charging system / Ignition system (carbureted models) / Ignition system (fuel-injected models) / Engine management system diagnostic codes / Cruise control system diagnostic codes / Fuel system (carbureted models) / Fuel system (electronic fuel injection) / Engine noises / Engine lubrication / Clutch / Transmission / Lighting system / Excessive vibration / Front suspension and steering / Brake problems / Specifications

CHAPTER THREE / LUBRICATION, MAINTENANCE AND TUNE-UP
Routine safety checks / Pre-ride inspection / Maintenance schedule intervals / Periodic lubrication / Oil and filter change / Oil tank flushing / Transmission oil change / Primary chaincase oil change / Drive chain lubrication / Control cable lubrication / Periodic maintenance / Primary chain adjustment / Drive belt deflection adjustment / Tune-up / Ignition service / Carburetor adjustments / Specifications

CHAPTER FOUR / ENGINE
Removal installation / Rocker arms and covers / Cylinder head / Valves and components / Cylinder / Pistons and rings / Pushrods and covers / Lifters and guides / Oil pump / Gearcase cover and timing gears / Crankcase and crankshaft / Engine break-in / Specifications

CHAPTER FIVE / CLUTCH AND PRIMARY DRIVE
Dry clutch / Wet clutch / Clutch shell, compensating sprocket and primary drive chain / Clutch shell, clutch hub and sprocket / Compensating sprocket / Primary chaincase / Electric starter drive / Starter jackshaft / Specifications

CHAPTER SIX / FOUR-SPEED TRANSMISSION
Shifter assembly / Shift forks / Transmission shafts / Main drive gear / Transmission case / Kickstarter / Starter clutch / Specifications

CHAPTER SEVEN / FIVE-SPEED TRANSMISSION
Production gears / Shifter assembly / Transmission shift cover / Shift cam / Shift forks / Transmission side door and transmission shaft / Transmission shafts / Main drive gear / Transmission side cover / Transmission drive sprocket / Transmission case / Transmission oil pan / Specifications

CHAPTER EIGHT / FUEL, EXHAUST AND EMISSION CONTROL SYSTEMS
Air filter back plate / Carburetor / Manifold / Electronic fuel injection EFI / Induction module / Fuel tank console / Fuel tank gauge / Fuel tank / Non-vacuum-operated fuel shutoff valve / Vacuum-operated fuel valve / Fuel pump and filter / Exhaust system / Evaporative emission control system / Specifications

CHAPTER NINE / ELECTRICAL SYSTEM
Battery / Charging system / Ignition system / Ignition module / Electronic control module / Ignition coil / Starting system / Starter solenoid / Starter relay / Lighting system / Headlight / Taillight brake light / Rear turn signal light / Passing light and front turn signal / Rear turn signal light / Instruments and indicator lights / Handlebar switches / Ignition/lighting switch / Oil pressure switch / Neutral indicator switch / Brake light switch / Horn / Turn signal and four-way flashers / Turn signal module / Speedometer speed sensor / Radio, CB and intercom systems / Electrical circuit protection / Circuit breaker / Electrical panel / Electrical connectors / Color wiring diagrams / Specifications

CHAPTER TEN / WHEELS, HUBS AND TIRES
Motorcycle stands / Front wheel / Front hub / Rear wheel / Rear hub / Driven sprocket assembly / Drive chain / Drive belt / Wheel runout / Rim and laced wheel service / Disc and alloy wheels / Wheel balance / Tires / Tire changing / Tire repairs / Tire runout / Specifications

CHAPTER ELEVEN / FRONT SUSPENSION AND STEERING
Handlebar / Front fork / Front fork air control and antidive system / Steering head and stem / Bearing race / Steering play / Specifications

CHAPTER TWELVE / REAR SUSPENSION
Shock absorbers / Air shock / Swing arm / Specifications

CHAPTER THIRTEEN / BRAKES
Front and rear pads / Front and rear caliper / Front and rear master cylinder / Brake hose and line / Brake disc / Bleeding / Specifications

CHAPTER FOURTEEN / CRUISE CONTROL
Cables / Servo motor / Cruise module control module and switch / Specifications

CHAPTER FIFTEEN / BODY
Seat / Front and rear fender / Fairing and windshield / Headlight nacelle / Tour-Pak / Saddlebags and guards / Footboards / Specifications

INDEX

COLOR WIRING DIAGRAMS
