Ford Transit Diesel 1986 - 1999 Workshop Manual (3019)

By: Haynes

Keep your Ford Transit Diesel in perfect running order and maintain its value with this workshop manual.

Models Covered

All Ford Transit models (including Tourneo) with normally-aspirated and turbocharged 2.5 litre (2496cc) Diesel engines.

Production years - 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998 and 1999.

Does NOT cover petrol engine or Transit 4x4 models, or specialist bodywork, conversions.

Inside the Manual
Service your car - complete step-by-step guide
Fault finding pinpoint specific problems easily
Pass the MOT - step-by-step test checks
Filters and fluids - checking and renewal
Braking system safety checks and repairs
Fuel system - explained
Electrical system fault finding and repairs
Engine - tune-up minor and major repairs
Wiring diagrams - easy-to-follow layout
Fully indexed - find information quickly
Introduction to the Ford Transit Diesel

The latest Ford Transit range of models was introduced in February 1986, and is the third generation of this popular range of vehicles. This manual covers the 2.5 litre Diesel engine models. The most obvious and distinctive features of the new range is the wedge-front styling, adopted to improve the aerodynamics. The 2.5 litre direct-injection Diesel engine is an overhead valve, water-cooled design with cast-iron cylinder head and cylinder block. Normally-aspirated and turbocharged versions are available. The engine is mounted in-line and, depending on model, is coupled to a four-speed, four-speed plus overdrive, or five-speed manual transmission, or a four-speed automatic transmission.

The steering and suspension on the short-wheelbase (LCX) models is new, being rack-and-pinion type with MacPherson strut independent front suspension. The long-wheelbase (LCY) models up to the 1992 model year continue with the worm-and-nut steering gear, and beam 1986 model Transit 100L long-wheelbase 1995 model Transit 80 short-wheelbase axle with leaf springs as used on earlier models. From 1992 onwards, all models are with rack-and-pinion steering and independent front suspension.

Telescopic double-acting shock absorbers are fitted to the front and rear suspension on all models. Drive to the rear wheels is by a two- or three-piece propeller shaft to the rear axle, which is suspended by single or multiple leaf springs on each side. All models are fitted with dual-circuit servo-assisted brakes, with discs at the front and self-adjusting drum brakes at the rear. Seemingly innumerable variations of body types and styles of Transit are available, from the Pick-up to the Caravanette. All body styles and variants are mounted on a long- or short-wheelbase chassis as necessary.

Other Details
Publisher Code: HA3019
ISBN 9781859605868
